Características:
Absorbe la experiencia internacional, la investigación independiente y el desarrollo de secador de mezcla de plástico, el soplado de aire caliente es uniforme, el efecto de secado es bueno, el tiempo de secado es corto, el control de temperatura es preciso.El regulador de alta precisión reduce el error de temperatura y ahorra tiempo y mano de obra.
Parámetros principales:
Model | WPHG-500 | WPHG-1000 | WPHG-2000 | WPHG-3000 |
Capacity | 500 kg | 1000 kg | 2000 kg | 3000 kg |
Motor power | 2.2 kW | 3 kW | 4 kW | 5.5 kW |
Blower power | 1.1 kW | 1.5 kW | 2.2 kW | 3 kW |
Heating power | 24 kW | 36 kW | 42 kW | 48 kW |
Material | 2mm stainless steel | 2.5mm stainless steel | ||
Main shaft | 60x4mm stainless steel seamless tube | |||
Center lifting diameter | 219mm stainless steel tube | 273mm stainless steel tube | ||
Center supportor | 32mm stainless steel tube | 38mm stainless steel tube | ||
Blade | 3mm stainless steel | |||
Rack | 80x80x3mm stainless steel square tube | 100x100x2mm stainless steel square tube | 120x120x3mm stainless steel square tube | 120x120x3mm stainless steel square tube |
Dimension | 2000×2000×2500mm | 2200×2200×2750mm | 2000×2200×3400mm | 2500×2500×3400mm |
Weight | 450 kg | 600 kg | 850 kg | 1150 kg |
Electrical appliances brand | TENGEN | |||
Remark | With material level alarm device | With material level alarm device and the access ladder | ||
