خلط مجفف

Model

WPHG-500

WPHG-1000

WPHG-2000

WPHG-3000

Capacity

500 kg

1000 kg

2000 kg

3000 kg

Motor power

2.2 kW

3 kW

4 kW

5.5 kW

Blower power

1.1 kW

1.5 kW

2.2 kW

3 kW

Heating power

24 kW

36 kW

42 kW

48 kW

Material

2mm stainless steel

2.5mm stainless steel

Main shaft

60x4mm stainless steel seamless tube

Center lifting diameter

219mm stainless steel tube

273mm stainless steel tube

Center supportor

32mm stainless steel tube

38mm stainless steel tube

Blade

3mm stainless steel

Rack

80x80x3mm  stainless steel square tube

100x100x2mm stainless steel square tube

120x120x3mm stainless steel square tube

120x120x3mm stainless steel square tube

Dimension

2000×2000×2500mm

2200×2200×2750mm

2000×2200×3400mm

2500×2500×3400mm

Weight

450 kg

600 kg

850 kg

1150 kg

Electrical appliances brand

TENGEN

Remark

With material level alarm device

With material level alarm device and the access ladder
