Features:
1. 304 stainless steel tank, tempered glass door
2. New optimized design of the stainlesssteel piping
3. Tractor remote control function
4. Application of European PE filters
5. Using China famous brand vacuum pump and water pump, ensure the pipe forming quality
Main parameter:
Model | Working range (mm) | Tank length (mm) | Tank thickness (mm) | Vacuum pump (kW) | Water pump (kW) | Moving motor power (kW) | Central height (mm) |
ZD-63 | 16-63 | 9000/5800 | 3 | 1.5+2.2 | 3+4 | 0.75 | 1000-1050 |
ZD-110 | 20-110 | 9000/5800 | 3 | 2.2+2.2 | 3+4 | 1.1 | 1000-1050 |
ZD-160 | 50-160 | 9000/5800 | 3 | 2.2+3 | 4+5.5 | 1.1 | 1000-1050 |
ZD-250 | 90-250 | 9000/5800 | 4 | 3+4 | 5.5+5.5 | 1.5 | 1000-1050 |
ZD-315 | 90-315 | 9000/5800 | 4 | 4+5.5 | 5.5+7.5 | 1.5 | 1000-1050 |
ZD-450 | 110-450 | 9000/5800 | 5 | 5.5+5.5 | 7.5+7.5 | 1.5 | 1100-1150 |
ZD-630 | 250-630 | 2400+9000 | 6 | 5.5+5.5*2 | 7.5+7.5*2 | 0.75+1.5 | 1100-1150 |
ZD-800 | 400-800 | 2400+9000 | 6 | 5.5+5.5*2 | 7.5+7.5*2 | 1.5 | 1200-1250 |
ZD-1000 | 500-1000 | 2400+10000 | 8 | 7.5+5.5*3 | 7.5+7.5*3 | 1.5 | 1400-1450 |
