Features:
1. Adopt rotary type blade to cut for smooth and flat notch
2. The feed system adopts hydraulic control for stable cutting
3. The electrical appliance adopts PLC control(Siemens) and the control panel adopts LCD test display for easily operated, and applies to match various pipe extrusion lines
Main parameter:
Model | Working range (mm) | Max. cutting thickness (mm) | Cutting motor power (kW) | Cutting type | Cutting speed (m/min) | Central height (mm) |
FD32 | 16-32 | 5 | 4.6 | Fly cutter | 1-50 | 1000-1050 |
WX-63 | 16-63 | 12 | 1.5 | Pneumatic dust-free cutting | 1.5-25 | 1000-1050 |
WX-110 | 20-110 | 20 | 2.2 | 0.4-10/ 0.6-20 | 1000-1050 | |
WX-160 | 20-160 | 20 | 2.2 | 0.2-10/ 0.6-20 | 1000-1050 | |
WX-250 | 75-250 | 25 | 2.2 | Hydraulic dust-free cutting | 0.2-3.5/ 0.3-10 | 1000-1050 |
WX-315 | 90-315 | 30 | 3 | 0.15-2.8 | 1000-1050 | |
WX-450 | 90-450 | 45 | 3 | 0.2-3.4 | 1100-1150 | |
WX-630 | 160-630 | 60 | 4 | 0.1-3 | 1100-1150 | |
WX-800 | 315-800 | 75 | 4 | 0.05-1.5 | 1200-1250 | |
WX-1000 | 400-1000 | 65 | 5.5 | 0.03-1.0 | 1400-1450 |
