خط أنابيب آلة قطع خالية من الغبار

Model

Working range (mm)

Max. cutting thickness (mm)

Cutting motor power (kW)

Cutting type

Cutting speed

(m/min)

Central height (mm)

FD32

16-32

5

4.6

Fly cutter

1-50

1000-1050

WX-63

16-63

12

1.5

Pneumatic dust-free cutting

1.5-25

1000-1050

WX-110

20-110

20

2.2

0.4-10/ 0.6-20

1000-1050

WX-160

20-160

20

2.2

0.2-10/ 0.6-20

1000-1050

WX-250

75-250

25

2.2

Hydraulic dust-free cutting

0.2-3.5/ 0.3-10

1000-1050

WX-315

90-315

30

3

0.15-2.8

1000-1050

WX-450

90-450

45

3

0.2-3.4

1100-1150

WX-630

160-630

60

4

0.1-3

1100-1150

WX-800

315-800

75

4

0.05-1.5

1200-1250

WX-1000

400-1000

65

5.5

0.03-1.0

1400-1450
