Features:
1. Caterpillar traction, independent frequency conversion drive motor
2. Famous frequency control
3. Can according to customer request, provide servo motor
Main parameter:
Model | Working range (mm) | Caterpillar quantity | Transmit type | Motor power (kW) | Traction length (mm) | Max. traction speed (m/min) | Central height (mm) |
QY-63 | 16-63 | 2 | Belt / Caterpillar | 2*1.5 | 1100 | 20 | 1000-1050 |
QY-110 | 20-110 | 2 | Caterpillar | 2*1.5 | 1300 | 12 | 1000-1050 |
QY-160 | 50-160 | 3 | 3*1.5 | 1500 | 8 | 1000-1050 | |
QY-250 | 90-250 | 4 | 4*1.1 | 1600 | 6 | 1000-1050 | |
QY-315 | 90-315 | 4 | 4*1.1 | 1800 | 4.5 | 1000-1050 | |
QY-450 | 110-450 | 6 | 6*1.1 | 1800 | 3 | 1100-1150 | |
QY-630 | 250-630 | 6 | 6*0.75 | 2100 | 1.5 | 1100-1150 | |
QY-800 | 400-800 | 8 | 8*0.75 | 2300 | 0.8 | 1200-1250 | |
QY-1000 | 500-1000 | 10 | 10*0.55 | 2500 | 0.5 | 1400-1450 |
