سحب بعيدا

Model

Working range (mm)

Caterpillar quantity

Transmit type

Motor power

(kW)

Traction length

(mm)

Max. traction speed (m/min)

Central height (mm)

QY-63

16-63

2

Belt / Caterpillar

2*1.5

1100

20

1000-1050

QY-110

20-110

2

Caterpillar

2*1.5

1300

12

1000-1050

QY-160

50-160

3

3*1.5

1500

8

1000-1050

QY-250

90-250

4

4*1.1

1600

6

1000-1050

QY-315

90-315

4

4*1.1

1800

4.5

1000-1050

QY-450

110-450

6

6*1.1

1800

3

1100-1150

QY-630

250-630

6

6*0.75

2100

1.5

1100-1150

QY-800

400-800

8

8*0.75

2300

0.8

1200-1250

QY-1000

500-1000

10

10*0.55

2500

0.5

1400-1450
