Features:
1. Suitable for butt welding of plastic pipes and fittings made of PE, PP in a ditch in worksite or workshop
2. Consists of basic frame, hydraulic unit, planning tool, heating plate,support for planning tool & heating plate, and optional parts
3. Removable PTFE coated heating plate with separate temperature control system
4. Electric planning tool
5. Low starting pressure ensures reliable welding quality of small pipes
6. Separate two-channel timer records time in soaking and cooling phases
7. High accurate and shockproof pressure meter indicates clearer readings
Main parameter:
Model | SHD160 | SHD250 | SHD315 | SHD355 | SHD450 | |
Pipe size(mm) | 63、75、90、110、125、140、160 | 90、110、125、140、160、180、200、225、250 | 90、110、125、140、160、180、200、225、250、280、315 | 90、110、125、140、160、180、200、225、250、280、315、355 | 200、225、250、280、315、355、400、450 | |
Heating plate max. temp | 270℃ | 270℃ | 270℃ | 270℃ | 270℃ | |
Temp. deviation in surface(170-250℃) | ≤±7℃ | ≤±7℃ | ≤±7℃ | ≤±7℃ | ≤±7℃ | |
Pressure adjustable ranges | 0-6.3 Mpa | 0-6.3 Mpa | 0-6.3 Mpa | 0-6.3 Mpa | 0-8 Mpa | |
Heating plate power | 1KW | 1 KW | 3.5 KW | 3.5 KW | 5.38 KW | |
Planning tool power | 1.1 KW | 1.1 KW | 1.1 KW | 1.1 KW | 1.5 KW | |
Hydraulic unit power | 0.75 KW | 0.75 KW | 0.75 KW | 0.75 KW | 1.5 KW | |
Total power | 2.85 KW | 3.85 KW | 5.35 KW | 5.35 KW | 8.38 KW | |
Working voltage | 220V/50HZ | 220V/50HZ | 220V/50HZ | 220V/50HZ | 380V/50HZ | |
Weight | 106 kg | 143 kg | 216 kg | 260 kg | 560 kg | |
Packing | Cases | 3plywood | 3plywood | 3plywood | 3plywood | 4plywood |
Volume | 0.58CBM | 0.70CBM | 1CBM | 1CBM | 3.16CBM | |
Model | SHD500 | SHD630 | SHD800 | SHD1000 | SHD1200 | |
Pipe size(mm) | 200、225、250、280、315、355、400、450、500 | 315、355、400、450、500、560、630 | 450、500、560、630、710、800 | 630、710、800、900、1000 | 630、710、800、900、1000、1100、1200 | |
Heating plate Max. temp | 270℃ | 270℃ | 270℃ | 270℃ | 270℃ | |
Temp. deviation in surface(170-250℃) | ≤±7℃ | ≤±7℃ | ≤±7℃ | ≤±7℃ | ≤±7℃ | |
Pressure adjustable ranges | 0-8 Mpa | 0-8 Mpa | 0-16 Mpa | 0-16 Mpa | 0-16 Mpa | |
Heating plate power | 9.35 KW | 9.35 KW | 12.5 KW | 17.5 KW | 21.5 KW | |
Planning tool power | 1.5 KW | 1.5 KW | 2.2 KW | 3 KW | 4 KW | |
Hydraulic unit power | 1.5 KW | 1.5 KW | 3 KW | 3 KW | 3 KW | |
Crane power | - | - | 0.5 KW | 0.5 KW | 1 KW | |
Total power | 12.35 KW | 12.35 KW | 18.2 KW | 24 KW | 29.5 KW | |
Working voltage | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | |
Weight | 700 kg | 780 kg | 1360 kg | 2600 kg | 2740 kg | |
Packing | Cases | 4 plywood | 4 plywood | 5 plywood | 5 plywood | 5 plywood |
Volume | 4.43CBM | 4.43CBM | 8.39CBM | --- | --- | |
