Features:
SZ serial vacuum pump is specially designed by our company for plasticextrusion equipment. It with outstanding features of compact structure, easy installation, large suction speed, high vacuum degree and low energy consumption. Compared with 2BV serial vacuum pump in the market, itcan be used by reducing one power grade. As a result, the energy consumption is greatly saved.
The high-quality stainless impeller is used for this serial vacuum pump. Besides, the anti-scale treatment with special technology is implemented for pumpinner chamber and equipped with the high-quality mechanical seal which is jointly developed by Sino-British joint venture enterprise and us. As a result, the service life ofvacuum pump is greatly extended.
This serial vacuum pump is the preferred product for plastic extrusion equipment including plastic pipe, profiles, wood-plastic and plastic granulation etc. it is also widely applied into many industries such as: food and pharmacy etc.
Main parameter:
Model | Suction Speed (m3/h) | Ultimate vacuum (Pa) | Power (kw) | Speed (r/min) | Supplied water (m3/h) | Weight (kg) |
SZ-0.3 | 20 | 4000 | 0.75 | 2820 | 0.20 | 32 |
SZ-0.5 | 40 | 1.5 | 2840 | 0.23 | 40 | |
SZ-1 | 60 | 2.2 | 2840 | 0.25 | 55 | |
SZ-1.5 | 90 | 3.0 | 2870 | 0.35 | 65 | |
SZ-2 | 120 | 4.0 | 2890 | 0.45 | 80 | |
SZ-3A | 180 | 5.5 | 1440 | 0.40 | 110 | |
SZ-4.5 | 270 | 7.5 | 1440 | 0.60 | 150 | |
SZ-6 | 360 | 11 | 1460 | 1.20 | 207 |
