Features:
1. Planetary cutting with saw blade
2. Powerful sawdust collector
3. Hydraulic feeding of blade with chamfering function
4. MITSUBISHI frequency converter for speed control
5. MITSUBISHI PLC control
6. Special hard alloy saw blade for thick pipe
Main parameter:
Model | Working range (mm) | Max. cutting thickness (mm) | Cutting motor power (kW) | Cutting type | Cutting speed (m/min) | Central height (mm) |
XX-63S | 20-63 | / | 2*1.1 | Saw blade cutting | 0.8-15 | 1000-1050 |
XX-110S | 50-110 | / | 2*2.2 | 0.3-6 | 1000-1050 | |
XX-160 | 50-160 | 20 | 2.2 | Planetary cutting | 0.3-6 | 1000-1050 |
XX-250 | 50-250 | 25 | 2.2 | 0.2-3.5 | 1000-1050 | |
XX-315 | 110-315 | 35 | 3 | 0.15-2.8 | 1000-1050 | |
XX-450 | 160-450 | 45 | 3 | 0.06-3 | 1100-1150 | |
XX-630 | 250-630 | 60 | 4 | 0.04-2 | 1100-1150 | |
XX-800 | 315-800 | 65 | 5.5 | 0.03-1.5 | 1200-1250 |
