Features:
1. Good for crushing PE, PVC, PPR pipe& fittings and sprue waste from injection-molded product, full fill production needs
2. Simple structure, low noise
3. Detachable moving blade, easy maintenance
4. Integrate shredding and collecting together, simple operation and easy maintenance
Main parameter:
Model | SWP400 | SWP500 | SWP560 | SWP630 | SWP730 | SWP900 |
Rotor diameter (mm) | 400 | 500 | 560 | 630 | 730 | 880 |
Fixed blades (Pcs) | 2 | 2 | 4 | 4 | 4 | 4 |
Moving blades (Pcs) | 5 | 5 | 10 | 10 | 10 | 14 |
Mesh Diameter (mm) | 10 | 12 | 14 | 14 | 16 | 18 |
Capacity(kg/h) | 250-350 | 450-550 | 550-650 | 700-800 | 900-1000 | 1100-1200 |
Feeding mouth (mm) | 400x300 | 430x500 | 470x500 | 520x550 | 650x700 | 850x700 |
Motor power (KW) | 15 | 22 | 30 | 37 | 55 | 90 |
Weight(kg) | 1300 | 1900 | 2400 | 2800 | 4500 | 6500 |
Dimensions (mm) | 2200x900x1800 | 2200x1050x2100 | 2300x1200x2250 | 2400x1300x2300 | 2600x1500x2700 | 2700x1580x2800 |
