Features:
1. Constant tension and line speed in coiling
2. Pneumatic control in coiling and uncoiling
3. Good coiling quality by mechanical guider (Also can equipped with servo motor as customer special request)
4. Machine warning device, Length-countingdevice, pressure tube device. (supplied if customer need)
Main parameter:
Model | Station | Pipe range(mm) | Coiling Diameter(mm) | Coiling Width (mm) | Coiling Height (mm) | Speed Range (m/min) | Motor Torque (N.m) |
JQ1S32 | Single station | 16-32 | 420-800 | 200-300 | 250 | 0.5-15 | 10 |
JQ2S32 | Double station | 16-32 | 420-800 | 200-300 | 250 | 0.5-15 | 10 |
JQ1S63 | Single station | 16-63 | 520-1800 | 300-500 | 300 | 0.5-18 | 25 |
JQ2S63 | Double station | 16-63 | 520-1800 | 300-500 | 300 | 5-20 | 25 |
JQ2S90 | Double station | 20-90 | 900-1800 | 350-650 | 350 | 5-20 | 25 |
JQ1S110 | Single station | 75-100 | 1600-2300 | 300-600 | 400 | 0.5-5 | 60 |
